FD-122SMV

FD-122SMV

A Legacy of Trust, Innovation, and Excellence


  • FEATURES


  1. High Performance for immersive surround applications
  2. Low frequency system with dual PI-grade insulation coating voice coil design for
  3. Power output from 200 w to 400w for satisfying different audio application
  4. Network  with high frequency protection for long time usage
  5. Input terminals located on top of cabinet for quick access
  6. Lightweight ABS cabinet with wall mount bracket for easy installation and adjustment
  7. Available for both wall-mounted and suspended ceiling installation.


  • SPECIFICATION


     Model     FD-122SMV
     Speaker unit     12"x1 + 1.75"x1
     Frequency Response       45Hz-20KHz
     Impedance     8Ω
     Rated  Power     400W
     Sensitivity     100dB
     H x V Angle     100° x 80°
     Crossover     1.5kHz
     Distortion     450 x 273 x 540
     Net Weight     9.8kg
